切菜機是根據市場上切割傳送帶的切刀改進而來的，能夠切割傳送帶對產品的污染。大型切菜機工作原理以及操作事項是怎樣的呢？下面來了解一下吧。
The vegetable cutter is improved according to the cutter of cutting conveyor belt in the market, which can eliminate the pollution of cutting conveyor belt to products. What is the working principle and operation of large vegetable chopper? Let's take a look.
切割后的產品會自由落入收集器中，了圓盤式和滾刀式切菜機的二次離心力粉碎現象。尺寸準確，適用于白菜、卷心菜、韭菜、芥菜、蒜苗、海帶、豆制品等莖、梗、葉類蔬菜的切、切絲、切片,是蔬菜加工、酸洗行業、大型、食堂、賓館等切菜的理想機器。
The cut products will fall into the collector freely, which eliminates the secondary centrifugal force crushing phenomenon of disc and hob vegetable cutters. It is suitable for cutting, shredding and slicing stem, stem and leaf vegetables such as cabbage, cabbage, leek, mustard, garlic seedling, kelp and bean products. It is an ideal machine for vegetable processing, pickling industry, large supermarkets, canteens and hotels.
切菜機工作原理：物料在進料槽的輸送帶上向前行進，經上壓帶夾緊壓緊后，送上下往復運動的立刀切段。然后將材料切成正方形或長方形。
Working principle of the vegetable cutter: the material moves forward on the conveyor belt of the feed chute, and is clamped and compressed by the upper pressure belt, and then sent to the vertical knife cutting section with reciprocating motion from top to bottom. Then cut the material into squares or rectangles.
切菜機的型號很多，不同的型號、不同的廠家、不同的時期，設備會有很大差異，因此很難在市場上直接獲得準確的報價。如上所述，山東給出的多功能大型切菜機合理，具體的切菜機市場報價，可以聯系所購買設備的廠家來說明產量、等級要求等，得到合理的和報價。
There are many models of vegetable chopper. The price of equipment will vary greatly with different models, manufacturers and periods, so it is difficult to obtain accurate quotation directly in the market. As mentioned above, the price of the multifunctional large-scale vegetable cutter given by Shandong is reasonable. For the specific market quotation of the vegetable cutter, you can contact the manufacturer of the purchased equipment to explain the output, grade requirements, etc., and get a reasonable recommendation and quotation.
切菜機的操作:機器連續工作前，必須行試切，觀察要切的蔬菜規格是否與要求的規格一致，否則應調整蔬菜的長度。滿足要求后才能正常工作。安裝立刀。打開防護罩，先轉動可調偏心輪，使刀架運動到下死點，然后將刀架抬高1/2mm，擰緊立刀與刀架連接的螺母。
Operation of vegetable chopper: before the machine works continuously, trial cutting must be carried out first to observe whether the specification of vegetables to be cut is consistent with the required specification, otherwise the length of vegetables should be adjusted. It can work normally only after meeting the requirements. Install the vertical knife. Open the protective cover, first rotate the adjustable eccentric to move the tool holder to the bottom dead center, then raise the tool holder by 1 / 2mm, and tighten the nut connecting the vertical knife and the tool holder.
安裝下刀刃。出廠時下刀刃與上刀配套。注意下刀刃必須與下刀刃中心對齊。切割長度的調整：觀察試切割的長度值是否與要求的長度一致，調整偏心塊的偏差距離，改變切割產品的長度。轉動可調偏心輪，松開連桿緊固螺釘，移動滑塊，由外向內，減少切割長度；移動滑塊，由內向外，增加切割長度，調整后擰緊調整螺絲。
Install the lower blade. When leaving the factory, the lower blade is matched with the upper blade. Note that the lower blade must be aligned with the center of the lower blade. Adjustment of cutting length: observe whether the length value of trial cutting is consistent with the required length, adjust the deviation distance of eccentric block and change the length of cutting products. Turn the adjustable eccentric, loosen the fastening screw of the connecting rod, move the slider from outside to inside, and reduce the cutting length; Move the slider from inside to outside, increase the cutting length, and tighten the adjusting screw after adjustment.
大型切菜機的保養：切菜機操作前應置于水平地面上，確保機器放置平穩，機插頭接觸良好，無松動、無水痕。檢查轉筒內或傳送帶上是否有異物。如果有異物，必須清理干凈，以免損壞工具。根據要加工的蔬菜選擇加工方式。離心切片機用于切瓜、土豆等硬質蔬菜。立刀部分可加工葉類軟質蔬菜或切片成不同規格的塊狀。丁字形、菱形等形狀。
Maintenance of large vegetable cutting machine: before operation, the vegetable cutting machine should be placed on the horizontal ground to ensure that the machine is placed stably, the machine plug is in good contact, and there is no looseness or water mark. Check whether there are foreign matters in the drum or on the conveyor belt. If there is any foreign matter, it must be cleaned to avoid damaging the tool. Select the processing method according to the vegetables to be processed. Centrifugal slicer is used to cut hard vegetables such as melons and potatoes. The vertical knife part can process leaf soft vegetables or slice them into blocks of different specifications. T-shape, diamond shape, etc.
安裝立刀并先轉動，調整偏心輪使刀架到達下死點，然后將刀架抬高1-2mm，使立刀與輸送機接觸皮帶，然后擰緊螺母并擰緊立刀。它固定在刀架上。如果刀架的高度很小，蔬菜可能會連接到刀上。如果刀架高度過大，可能會切斷傳送帶。
Install and rotate the vertical knife first, adjust the eccentric wheel to make the knife rest reach the bottom dead center, then raise the knife rest by 1-2mm to make the vertical knife contact with the conveyor belt, and then tighten the nut and tighten the vertical knife. It is fixed on the tool holder. If the height of the knife holder is small, the vegetables may be connected to the knife. If the tool holder height is too high, the conveyor belt may be cut off.
大型切菜機工作原理以及操作事項經過以上的講解，大家應該有所了解了，當然在使用之前要知道做好檢查以及保養工作，更多內容就來網站
www.whrjcs.com進行咨詢吧。
After the above explanation, you should understand the working principle and operation of the large vegetable chopper. Of course, you should know to check and maintain it before use. For more information, please visit www.whrjcs.com Com.
